PM 8523 P
The PM 8523 P is a lightweight yet powerful articulating crane designed to deliver exceptional lifting performance with remarkable outreach, all while keeping operational efficiency and versatility at the forefront.
Compare products
Product Specs
- Fuel Tank Capacity 64 l
- Hydraulic Horizontal Outreach 8.85 m
- Hydraulic Vertical Outreach 11.70 m
- Max. Lifting Moment 6.3 TM
- Max. Pressure 28 MPa
- Recommended oil flow 30 l/min
- Slewing angle 400°
- Slewing torque 10.0 kNm
- Stabilizer control Radio Wireless Manual
- Stabilizer Spread available 3.2 – 4.2 m
- Standard Crane Weight with empty tank 1000 kg
Product description
Compact Power, Maximum Reach
Part of the renowned PM 8.5 P series, the PM 8523 P combines high lifting capacity with an impressively low crane weight, making it the perfect solution for demanding lifting tasks where space and payload matter. With a maximum lifting moment of 6.3 tonne-meters, this crane achieves a horizontal outreach of 8.85 meters and a vertical reach of 11.70 meters—offering outstanding coverage for a wide range of applications. The Plus system enhances crane performance, providing smooth, precise operation under various working conditions. Its robust 400° slewing system with a 10.0 kNm torque ensures reliable rotation and flexibility even in tight job sites. Stabilization is easy and secure with manual stabilizer controls and adjustable spreads from 3.2 to 4.2 meters. Engineered for efficiency, the PM 8523 P operates with a recommended oil flow of just 30 liters per minute and a maximum pressure of 28 MPa, optimizing energy use without compromising power. Weighing only 1,000 kg with an empty tank, this crane helps maximize vehicle payload while delivering top-class performance.
