PM 50.5 SP / SP C

The PM 50.5 SP combines high lifting performance with advanced electronic control, ensuring maximum efficiency, reliability, and operator safety for demanding applications.

Get in touch

Series Specs

Metric Imperial

	PM 50522 SP	PM 50522 SP C	PM 50523 SP	PM 50523 SP C	PM 50524 SP	PM 50524 SP C	PM 50525 SP	PM 50525 SP C	PM 50526 SP	PM 50526 SP C
Fuel Tank Capacity	200 l	200 l	200 l	200 l	200 l	200 l	200 l	200 l	200 l	200 l
Height	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″	8′ 2″
Height	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm	2500 mm
Hydraulic Horizontal Outreach	26′ 1″	23′	31′ 6″	28′ 5″	38′ 7″	35′ 5″	45′ 11″	42′ 10″	53′ 8″	50′ 6″
Hydraulic Horizontal Outreach	7,95 m	7,00 m	9,60 m	8,65 m	11,75 m	10,80 m	14,00 m	13,05 m	16,35 m	15,40 m
Hydraulic Vertical Outreach	41′ 10″	36′ 11″	46′ 11″	42′ 2″	53′ 8″	49′ 3″	60′ 6″	56′ 5″	67′ 11″	64′
Hydraulic Vertical Outreach	12,75 m	11,25 m	14,30 m	12,85 m	16,35 m	15,00 m	18,45 m	17,20 m	20,70 m	19,50 m
Length	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″	8′ 4″
Length	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm	2550 mm
Max. Lifting Moment	350350 ft Ibs	337900 ft Ibs	326720 ft Ibs	314780 ft Ibs	321780 ft Ibs	305510 ft Ibs	314420 ft Ibs	299450 ft Ibs	311020 ft Ibs	293260 ft Ibs
Max. Lifting Moment	48,4 TM	46,7 TM	45,2 TM	43,5 TM	44,5 TM	42,2 TM	43,5 TM	41,4 TM	43,0 TM	40,5 TM
Max. Pressure	34.5 MPa	31,5 MPa	34.5 MPa	31,5 MPa	34.5 MPa	31,5 MPa	34.5 MPa	31,5 MPa	34.5 MPa	31,5 MPa
Recommended oil flow	80 – 100 l/min	40 – 80 l/min	80 – 100 l/min	40 – 80 l/min	80 – 100 l/min	40 – 80 l/min	80 – 100 l/min	40 – 80 l/min	80 – 100 l/min	40 – 80 l/min
Slewing angle	395°	395°	395°	395°	395°	395°	395°	395°	395°	395°
Slewing torque	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m	53 kN m
Stabilizer control Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless
Stabilizer Spread available	6,6 – 8.0 m	6,6 – 8.0  m	6,6 – 8.0 m	6,6 – 8.0  m	6,6 – 8.0 m	6,6 – 8.0  m	6,6 – 8.0 m	6,6 – 8.0  m	6,6 – 8.0 m	6,6 – 8.0  m
Width	4′ 4″	4′ 4″	4′ 4″	4′ 4″	4′ 4″	4′ 4″	4′ 4″	4′ 4″	4′ 8″	4′ 8″
Width	1330 mm	1330 mm	1330 mm	1330 mm	1330 mm	1330 mm	1330 mm	1330 mm	1420 mm	1420 mm
Spec Sheet

Product description

Elevate to the highest power.

As part of the Gold line, the PM 50.5 SP Series is designed to deliver uncompromising power and precision. With the exclusive PM link system, the crane maintains constant performance across all working configurations, optimizing outreach and efficiency. The Power Tronic Advance Plus system, combined with a multifunction radio control featuring a display, ensures operators benefit from real-time feedback, precise maneuvering, and enhanced safety during every lifting operation.

Available in configurations with up to six hydraulic extensions, the PM 50.5 SP achieves a horizontal outreach of 15.4 m and a vertical outreach of 19.5 m. Its robust slewing system provides a rotation angle of 395° and torque of 53 kNm, delivering smooth and dependable operation even in intensive cycles. A negative boom angle of 15° adds flexibility, particularly in confined spaces, while optional XL (6.6 m) and XXL (8 m) stabilizers provide maximum stability on challenging terrain.

Operators can choose the standard or “C” version, with the latter offering enhanced capability for lifting heavy loads at short range. Despite its power, the PM 50.5 SP maintains compact dimensions and a crane weight starting at just over 5 tonnes, making it suitable for installation on a wide range of vehicles.

Balancing strength, advanced technology, and flexibility, the PM 50.5 SP is the perfect solution for operators who demand maximum productivity and precision in medium-heavy lifting applications.
