PM 3.6

The PM 3.6 combines increased lifting power, extended outreach, and dependable performance—ideal for versatile loading and unloading tasks.

Get in touch

Series Specs

Metric Imperial

	PM 3621	PM 3622	PM 3623
Fuel Tank Capacity	36 l	36 l	36 l
Height	5′ 3″	5′ 3″	5′ 3″
Height	1605 mm	1605 mm	1605 mm
Hydraulic Horizontal Outreach	16′ 1″	20′ 8″	25′ 1″
Hydraulic Horizontal Outreach	4,90 m	6,30 m	7,65 m
Hydraulic Vertical Outreach	25′ 3″	29′ 6″	33′ 8″
Hydraulic Vertical Outreach	7,70 m	9,00 m	10,25 m
Length	6′ 2″	6′ 2″	6′ 2″
Length	1880 mm	1880 mm	1880 mm
Max. Lifting Moment	21150 ft lbs	20710 ft lbs	20250 ft lbs
Max. Lifting Moment	2,9 TM	2,9 TM	2,8 TM
Max. Pressure	25 MPa	25 MPa	25 MPa
Recommended oil flow	12 l/min	12 l/min	12 l/min
Slewing angle	360°	360°	360°
Slewing torque	4,5 kN m	4,5 kN m	4,5 kN m
Stabilizer control Radio Wireless	Manual	Manual	Manual
Stabilizer Spread available	3.5 m	3.5 m	3.5 m
Width	1′ 8″	1′ 8″	1′ 8″
Width	500 mm	500 mm	500 mm
Spec Sheet

Product description

Power, productivity, reliability.

The Tadano PM 3.6 is an articulating crane designed for efficiency in small to medium operations. With a maximum lifting moment of up to 2.9 tonne-meters and vertical outreach reaching 10.25 meters, it provides excellent reach and lifting strength. Compact dimensions and transport-optimized weight (425–480 kg depending on configuration) allow easy installation on light vehicles. Operators can choose from configurations such as the 3621, 3622, or 3623, with horizontal reaches ranging from 4.9 to 7.65 meters. Safety is supported by manual stabilizers with spreads up to 3.5 meters and a robust 360° slewing system. Built to handle daily lifting challenges, the PM 3.6 articulating crane ensures the right balance of strength, reach, and reliability.
