PM 23 P

The PM 23 P delivers advanced hydraulics, electronic precision, and reliable strength—making it a top performer in the medium crane range.

Get in touch

Series Specs

Metric Imperial

	PM 23022 P	PM 23023 P	PM 23023 P + J512.20	PM 23023 P + J513.20	PM 23024 P	PM 23024 P + J512.20	PM 23024 P + J513.20	PM 23024 P + J514.20	PM 23025 P	PM 23026 P	PM 23027 P
Fuel Tank Capacity	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l
Height	7′ 5”	7′ 5”	8′ 3″	8′ 3″	7′ 5”	8′ 3″	8′ 3″	8′ 3″	7′ 5”	7′ 5”	7′ 5”
Height	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm	2520 mm
Hydraulic Horizontal Outreach	26′ 3”	33′ 6”	52′ 10″	58′ 7″	41′ 0”	60′ 2″	65′ 11″	71′ 8″	48′ 5”	55′ 11”	63′ 4”
Hydraulic Horizontal Outreach	8,00 m	10,20m	16,10 m	17,85 m	12,50 m	18,35 m	20,10 m	21,85 m	14,75 m	17,05 m	19,30 m
Hydraulic Vertical Outreach	39′ 1”	46′ 1”	65′ 7″	71′ 2″	53′ 4”	76′ 1″	78′ 5″	83′ 12″	60′ 8”	67′ 11”	74′ 12”
Hydraulic Vertical Outreach	11,90 m	14,05 m	20,00 m	21,70 m	16,25 m	23,20 m	23,90 m	25,60 m	18,50 m	20,70 m	22,85 m
Length	8′ 1”	8′ 1”	8′ 2″	8′ 2″	8′ 1”	8′ 2″	8′ 2″	8′ 2″	8′ 1”	8′ 1”	8′ 1”
Length	2460 mm	2460 mm	2500 mm	2500 mm	2460 mm	2500 mm	2500 mm	2500 mm	2460 mm	2460 mm	2460 mm
Max. Lifting Moment	148280 ft Ibs	142490 ft Ibs	142490 ft Ibs	142490 ft Ibs	139600 ft Ibs	139600 ft Ibs	139600 ft Ibs	139600 ft Ibs	135980 ft Ibs	133090 ft Ibs	131640 ft Ibs
Max. Lifting Moment	20,5 TM	19,7 TM	19,7 TM	19,7 TM	19,3 TM	19,3 TM	19,3 TM	19,3 TM	18,8 TM	18,4 TM	18,2 TM
Max. Pressure	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa
Recommended oil flow	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min
Slewing angle	400°	400°	400°	400°	400°	400°	400°	400°	400°	400°	400°
Slewing torque	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m
Stabilizer control Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless
Stabilizer Spread available	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m
Width	3′ 2”	3′ 2”	3′ 11″	3′ 11″	3′ 2”	3′ 11″	3′ 11″	3′ 11″	3′ 4”	3′ 5”	3′ 7”
Width	965 mm	965 mm	1205 mm	1205 mm	965 mm	1205 mm	1205 mm	1205 mm	1025 mm	1045 mm	1080 mm
Spec Sheet

Product description

Power and precision in perfect balance.

The Tadano PM 23 P Series belongs to the Classic Plus line, combining high performance with cutting-edge control. Equipped as standard with a proportional hydraulic control valve block and multi-function radio control with display, it ensures smooth, precise movements and safe operation. The integrated Plus system enhances lifting power and control of crane dynamics, while the PM Power Tronic electronic management system provides real-time monitoring across all working conditions.

Operators can select from models 23022 through 23027. Depending on the configuration, maximum lifting moments reach up to 19.7 tonne-meters, with horizontal outreaches ranging from 12.5 m to 19.3 m and vertical outreach up to 22.85 m . The LC version, available across the series, features a hydraulically retractable first boom for handling bulky or heavy loads at close range.

For added versatility, jib options with 2, 3, or 4 extensions are available on the 3- and 4-extension base models. These increase maximum outreach to 21.85 m horizontally and 25.60 m vertically. The robust cast iron slewing unit ensures intensive use with a 400° slewing angle and 27.3 kNm torque.

Safety is supported by multiple stability options, including Type 1, 3, 4, and 5 Interlock systems . Combining versatility, power, and precision, the PM 23 P Series is designed to meet the demands of operators working in challenging and diverse applications.
