PM 21

The PM 21 delivers efficiency, flexibility, and excellent value—making it a versatile solution for medium-capacity lifting needs.

Get in touch

Series Specs

Metric Imperial

	PM 21022	PM 21023	PM 21024	PM 21025	PM 21026	PM 21027
Fuel Tank Capacity	150 l	150 l	150 l	150 l	150 l	150 l
Height	7′ 5″	7′ 5″	7′ 5″	7′ 5″	7′ 5″	7′ 5″
Height	2250 mm	2250 mm	2250 mm	2250 mm	2250 mm	2250 mm
Hydraulic Horizontal Outreach	26′ 3”	33′ 6”	41′ 0”	48′ 5”	55′ 11”	63′ 4”
Hydraulic Horizontal Outreach	8,00 m	10,20 m	12,50 m	14,75 m	17,05 m	19,30 m
Hydraulic Vertical Outreach	39′ 1”	46′ 1”	53′ 4”	60′ 8”	67′ 11”	74′ 12”
Hydraulic Vertical Outreach	11,90 m	14,05 m	16,25 m	18,50 m	20,70 m	22,85 m
Length	8′ 1″	8′ 1″	8′ 1″	8′ 1″	8′ 1″	8′ 1″
Length	2460 mm	2460 mm	2460 mm	2460 mm	2460 mm	2460 mm
Max. Lifting Moment	137430 ft Ibs	132360 ft Ibs	128750 ft Ibs	126580 ft Ibs	119340 ft Ibs	117170 ft Ibs
Max. Lifting Moment	19,0 TM	18,3 TM	17,8 TM	17,5 TM	16,5 TM	16,2 TM
Max. Pressure	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa
Recommended oil flow	40 l/min	40 l/min	40 l/min	40 l/min	40 l/min	40 l/min
Slewing angle	400°	400°	400°	400°	400°	400°
Slewing torque	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m	27,3 kN m
Stabilizer control Radio Wireless	Manual	Manual	Manual	Manual	Manual	Manual
Stabilizer Spread available	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m
Width	3′ 2”	3′ 2”	3′ 2”	3′ 4”	3′ 5”	3′ 7”
Width	965 mm	965 mm	965 mm	1025 mm	1045 mm	1085 mm
Spec Sheet

Product description

Flexible power, simplified.

The Tadano PM 21 Series belongs to the Classic line, combining structural simplicity with powerful performance. With lifting moments from 16.2 to 17.8 tonne-meters depending on model, it delivers reliable strength while ensuring straightforward operation.

Operators can select from configurations 21022 through 21027, with horizontal outreaches ranging from 12.5 m up to 19.3 m and vertical outreaches from 16.25 m up to 22.85 m. The 7-extension version (21027) represents a major innovation, providing industry-leading reach at this capacity class. An LC version is also available, featuring a hydraulically retractable first boom to handle heavy or bulky loads at close range while optimizing loading under the column.

As standard, the PM 21 Series includes a manual hydraulic control valve block, while optional Interlock Type 1 and 2 systems further enhance stability. Slewing is supported by a 400° rotation angle and 27.3 kNm torque, ensuring dependable maneuverability across repeated cycles.

Practical, flexible, and cost-effective, the PM 21 Series is built to maximize performance while ensuring an excellent return on investment.
