PM 2.8
The PM 2.8 articulating crane delivers compact strength, versatile outreach, and reliable performance—perfect for small-scale loading and unloading tasks.
Series Specs
| PM 2821 | PM 2822 | PM 2823 | |
|---|---|---|---|
| Fuel Tank Capacity | 25 l | 25 l | 25 l |
| Height | 5′ 1” | 5′ 1” | 5′ 1” |
| Height | 1540 mm | 1540 mm | 1540 mm |
| Hydraulic Horizontal Outreach | 15′ 55” | 20′ 0” | 24′ 7” |
| Hydraulic Horizontal Outreach | 4,70 m | 6,10 m | 7,50 m |
| Hydraulic Vertical Outreach | 24′ 7” | 28′ 10” | 33′ 2” |
| Hydraulic Vertical Outreach | 7,50 m | 8,80 m | 10,10 m |
| Length | 5′ 11” | 5′ 11” | 5′ 11” |
| Length | 1800 mm | 1800 mm | 1800 mm |
| Max. Lifting Moment | 18230 ft Ibs | 17540 ft Ibs | 17210 ft Ibs |
| Max. Lifting Moment | 2,5 TM | 2,4 TM | 2,4 TM |
| Max. Pressure | 23 MPa | 23 MPa | 23 MPa |
| Recommended oil flow | 12 l/min | 12 l/min | 12 l/min |
| Slewing angle | 360° | 360° | 360° |
| Slewing torque | 25 kNm | 24 kNm | 24 kNm |
| Stabilizer control Radio Wireless | Manual | Manual | Manual |
| Stabilizer Spread available | 3.5 m | 3.5 m | 3.5 m |
| Width | 1′ 8” | 1′ 8” | 1′ 8” |
| Width | 500 mm | 500 mm | 500 mm |
| Spec Sheet |  | | |
Product description
Power, productivity, reliability.
The Tadano PM 2.8 is an articulating crane designed for efficiency in everyday lifting operations. With a maximum lifting moment of 2.5 tonne-meters and outreach options up to 10.1 meters vertically, it provides exceptional reach in confined spaces. The crane is equipped with a 360° slewing system and manual stabilizers for dependable operation, while a recommended oil flow of 12 l/min and a maximum pressure of 23 MPa ensure smooth hydraulic performance.
Compact dimensions and transport-optimized weight (395–450 kg depending on model) allow easy installation on light vehicles. Operators can choose from configurations such as the 2821, 2822, or 2823, with horizontal reaches ranging from 4.7 to 7.5 meters. Safety is supported by manual controls and robust stabilizer spreads up to 3.5 meters. Built to handle repetitive loading tasks, the PM 2.8 Classic articulating crane delivers the ideal balance of portability, performance, and durability for small to medium lifting applications.
Vehicle Type
-
3.50 ton
771617 lbs
-
5.00 ton
1102310 lbs
-
6.00 ton
1322772 lbs
-
6.50 ton
1433003 lbs
-
7.50 ton
1653465 lbs
-
8.00 ton
1763696 lbs
-
10.00 ton
2204620 lbs
-
12.00 ton
2645544 lbs
-
13.50 ton
2976237 lbs
-
15.00 ton
3306930 lbs
-
18.00 ton
3968316 lbs
-
19.00 ton
4188778 lbs
-
26.00 ton
5732012 lbs
-
32.00 ton
7054784 lbs
-
44.00 ton
9700328 lbs
- 2 Stabilizers STANDARD
- 2 Stabilizers XL
- 4 Stabilizers
