PM 18 SP

The PM 18 SP combines advanced electronics, superior control, and extended outreach—delivering premium performance in the medium crane range.

Get in touch

Series Specs

Metric Imperial

	PM 18022 SP	PM 18023 SP	PM 18023 SP + J512.20	PM 18023 SP + J513.20	PM 18024 SP	PM 18024 SP + J512.20	PM 18024 SP + J513.20	PM 18024 SP + J514.20	PM 18025 SP	PM 18025 SP + J252	PM 18026 SP	PM 18027 SP
Fuel Tank Capacity	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l	150 l
Height	7′ 5″	7′ 5″	8′ 8″	8′ 8″	7′ 5″	8′ 9″	8′ 9″	8′ 9″	7′ 7″	8′ 2″	7′ 9″	7′ 11″
Height	2250 mm	2250 mm	2645 mm	2645 mm	2250 mm	2660 mm	2660 mm	2660 mm	2305 mm	2500 mm	2365 mm	2405 mm
Hydraulic Horizontal Outreach	25′ 5″	32′ 8″	52′ 4″	58′ 3″	40′ 2″	60′ 2″	65′ 9″	71′ 4″	47′ 7″	65′ 9″	55′ 1″	62′ 6″
Hydraulic Horizontal Outreach	7,75 m	9,95 m	15,95 m	17,75 m	12,25 m	18,35 m	20,05 m	21,75 m	14,50 m	20,05	16,80 m	19,05 m
Hydraulic Vertical Outreach	38′ 7″	45′ 7″	65′ 9″	71′ 6″	52′ 12″	73′ 2″	79′ 1″	84′ 10″	60′ 6″	79′ 1″	67′ 11	75′ 4″
Hydraulic Vertical Outreach	11,75 m	13,90 m	20,05 m	21,80 m	16,15 m	22,30 m	24,10 m	25,85 m	18,45 m	24,10 m	20,70 m	22,95 m
Length	8′ 1″	8′ 1″	8′ 2″	8′ 2″	8′ 1″	8′ 2″	8′ 2″	8′ 2″	8′ 1″	8′ 2″	8′ 1″	8′ 1″
Length	2455 mm	2455 mm	2500 mm	2500 mm	2455 mm	2500 mm	2500 mm	2500 mm	2455 mm	2500 mm	2455 mm	2455 mm
Max. Lifting Moment	117170 ft lbs	114280 ft lbs	114280 ft lbs	114280 ft lbs	110670 ft lbs	110670 ft lbs	110670 ft lbs	110670 ft lbs	108500 ft lbs	108500 ft lbs	105600 ft lbs	104880 ft lbs
Max. Lifting Moment	16,2 TM	15,8 TM	15,8 TM	15,8 TM	15,3 TM	15,3 TM	15,3 TM	15,3 TM	15,0 TM	15,0 TM	14,6 TM	14,5 TM
Max. Pressure	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa	30,5 MPa
Recommended oil flow	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min	80 l/min
Slewing angle	400°	400°	400°	400°	400°	400°	400°	400°	400°	400°	400°	400°
Slewing torque	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m	19,7 kN m
Stabilizer control Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless	Radio Wireless
Stabilizer Spread available	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m	5,1 – 6.6 m
Width	3′ 2″	3′ 2″	4′	4′	3′ 2″	4′	4′	4′	3′ 4″	4′	3′ 5″	3′ 7″
Width	965 mm	965 mm	1210 mm	1210 mm	965 mm	1210 mm	1210 mm	1210 mm	1025 mm	1210 mm	1045 mm	1085 mm
Spec Sheet

Product description

Power, precision, and versatility.

The Tadano PM 18 SP Series is one of the most advanced cranes in the medium category, designed with cutting-edge mechanics and electronics for maximum productivity. With lifting moments from 14.5 to 15.3 tonne-meters depending on configuration, it provides reliable strength with compact weight and modern design.

Operators can choose from a wide range of models, including the 18022 through 18027 SP. Outreach varies from 14.5 m up to 19.05 m horizontally and from 18.45 m up to 23.0 m vertically. The 7-extension version (18027 SP) represents a breakthrough in this class, achieving 19.05 m horizontal and 22.95 m vertical reach. Jib-equipped versions, such as the 18023 SP +J512 and 18024 SP +J514.20, extend working ranges further, up to 21.75 m horizontally and 25.85 m vertically.

As part of the Gold line, the PM 18 SP includes the Plus system for enhanced lifting power, a compensated proportional hydraulic valve block, multifunction radio remote with display, and a heat exchanger for consistent performance. The PM Power Tronic electronic management system gives operators real-time monitoring of crane dynamics, while the double connecting rod system ensures constant lifting curves and smooth operation. An LC version is also available for short-range heavy lifts and loading close to the column.

Versatile, precise, and highly equipped, the PM 18 SP Series sets a new benchmark for efficiency and safety in the medium crane range.
