ATF 110G-5
Tremendous strength, great charts, relentless technology updates, and a self-setting jib with optional integrated heavy-duty jib to handle almost any lifting need.
Compare products
Product Specs
- Max. Crane Capacity 130 USt
- Main Boom Length 42.7 ft – 170.6 ft
- Boom Extension 12.4 ft – 104.9 ft
- Max. Tip Height 283.7 ft
- Max. Counterweight 82,453 lbs
- Outrigger Bases 26.3 ft – 24.6 ft
- Hoist Line Pull 19,108 lbs
- MAX Radius 209.9 ft
- Dimensions L: 48.7 ft W: 9.0 ft H: 13.0 ft
- Max. Crane Capacity 110 t
- Main Boom Length 13 m – 52 m
- Boom Extension 3.8 m – 32 m
- Max. Tip Height 88 m
- Max. Counterweight 36 t
- Outrigger Bases 8.03 m x 7.50 m
- Hoist Line Pull 8.7 t
- Max. Radius 64 m
- Dimensions L: 14.93 m W: 2.75 m H: 3.99 m
- Axles 5
- Engine Mercedes-Benz
- Drive 10 x 6 x 10 (10 x 8 x 10)
Product description
Updated with More Strength and Operating Convenience
The ATF 110G-5 continuously offers high load capacity with relentless technology updates. This crane lifts 110t / 130 USt; it’s the crane of choice for rig moves in oil fields thanks to its tremendous strength and great charts for long booms. The ATF 110G-5 possesses a high load capacity at 10m / 32.8 ft radius, 21.9m / 71.9 ft, and main boom up to 40.7t / 44.8 USt. With the self-setting jib up to 40t / 44 USt lifting capacity; an integrated heavy-duty jib can be added. Counterweights are designed for flexible transport due to logical and small part divisions. This crane efficiently and easily serves almost all lifting purposes.
