GR-500EXL

The GR-500EXL combines strong lift capacity and lifting height with advanced monitoring features that detects extended outriggers, saves fuel, and reduces emissions and noise.

Product Specs

  • Capacity Class 51 t
  • Main Boom Length 11.1 m – 42.0 m
  • Boom Extension 8.0 m / 12.7 m
  • Outrigger Bases 7.0 m x 7.0 m
  • Hoist Line Pull 44.1 kN
  • Max. Radius 44.2 m
  • Dimensions 13.39 m L x 2.96 m W x 3.86 m H
  • Axles 2
  • Drive 4x4x4

Product description

50 Tons of Capacity with Advanced Monitoring

The Tadano GR-500EXL, equipped with a Mitsubishi engine, boasts a maximum lift capacity of 50 tonnes and a maximum lifting height of 42.4 meters (boom) and 56.0 meters (boom + jib). Standard features include HELLO-NET, a telematics system that facilitates crane management by providing detailed information on operational status, position, and maintenance. Additionally, it incorporates the AML-C system, which detects the extension width of outriggers at all four corners to optimize work efficiency across different areas. The system continuously monitors fuel consumption during crane operations, idling, and travel, allowing operators to optimize fuel efficiency while reducing emissions and noise levels. Furthermore, the ECO Mode system is implemented to reduce fuel consumption by up to 40%.

The Tadano Advantage

Tadano’s legendary reputation for quality and innovation is why we lead the lifting industry. Superior engineering, design, and components followed up with top-notch service means a greater rate of return and the lowest owning and operating cost of any crane on the market.
